VARIANT-36
18,800 CFM from a 36-inch, five-blade fan on an EC direct-drive motor. Fill the 60-gallon tank, plug into a standard 110 V outlet and cool a rated 5,100 sq ft.
- Airflow
- 18,800 CFM (31,900 m³/h)
- Cooling area
- 5,100 sq ft (474 m²)
- Air throw
- Up to 85 ft1 (26 m)Farthest reach of the airflow.
- Fan diameter
- 36 in (914 mm)
- Speed control
- Variable 1-100 speeds
- Power
- 0.75 kW
- Motor
- EC direct drive
- Voltage
- 110 V
- Cord length
- 15 ft (4.6 m)
- Water tank
- 60 gal (227 L)
- Water use
- 2.6–4.0 gal/hr (10–15 L/hr)
- Cooling media
- 3-section pad, 60 × 60 × 6 in (1,524 × 1,524 × 152 mm)
- Net weight
- 210 lb (95 kg)
- Dimensions
- 71 × 63 × 30 in (1,803 × 1,600 × 762 mm)
- SKU
- BCO36
Ships by LTL freight with a $0 shipping fee, the next business day, Monday to Friday. Freight usually takes 1 to 3 business days. Every unit is palletized and strapped, so a forklift or a standard dually can take delivery.
Prefer to collect? Choose in store pick-up in Fresno: orders placed before 2:00 pm are processed the same day.
A 3-year limited warranty from the date of purchase covers defects in materials and workmanship under normal use. Read the warranty.
Split your purchase into bi-weekly or monthly payments with Shop Pay Installments at checkout. No hidden fees, and no impact on your credit score to apply. How financing works.
For warehouses, workshops, hangars and job sites.
Watch the video
Roll it to wherever the heat is. A 36-inch fan on an EC direct-drive motor moves 18,800 CFM from a standard 110 V outlet.
- 18,800CFM airflow
- 5,100sq ft rated area
- 3-yearLimited warranty
A 36-inch fan. 18,800 CFM.
The VARIANT-36 covers a rated 5,100 sq ft. Point it down a loading dock, a warehouse aisle or a hangar, then set the speed on the control panel to suit the space.
Ask about larger orders
Drag to turn it. On a smartphone, place a full-size VARIANT-36 in your own space with AR and walk around it in real time.
- Cooling coverage5,100 sq ftRated area, 474 m².
- Power supply0.75 kWAll 18,800 CFM at 0.75 kW.
- Plug type110 VA standard outlet, on a 15 ft cord.
- Water tank60 gal227 L, using 2.6–4.0 gal/hr.
Save energy, stay cool.
Massive water pad
A multi-piece 60 × 60 × 6 in pad gives the air a large, evenly flowing surface of water to pass through, and a valve sets how much water reaches it.
EC-drive motor
18,800 CFM from a direct-drive motor: no belts, ever. Variable speed lets you set the airflow to suit the space, and the motor is bolted to an aviation-grade, five-blade fan hub.
Exoskeleton frame
Galvanized exoskeleton framing wraps the textured, antibacterial housing and protects it from heat, flexing and warping, rough handling, water corrosion, drops and forklift knocks. Because durability is reliability.
PAG impeller
Injection-molded PAG fan blades on an aluminum hub machined for dynamic balance and efficient performance.
Control panel
The LCD control panel runs the EC drive’s variable speed. Save your preferred start and stop settings in the panel, so the cooler comes on the way you left it.
Energy efficiency
The motor moves 18,800 CFM while drawing only about 0.75 kW, from a standard 110 V outlet.
Water valve adjustment
Turn the valve on the side of the machine to set the water flow. Open it all the way in a heat wave; dial it down when the air is muggy, to suit the humidity where you are.
Temperature reduction
Evaporative cooling brings the temperature down while using very little energy. How far depends on the building and the local climate.
What goes into the VARIANT-36.
EC direct-drive motor
18,800 CFM · No belts
Exoskeleton framing
Built tough · Galvanized frame
Airflow at your fingertips
1-100 customizable fan speeds
Advanced aluminum hub
Aviation grade · Five blades
